· Ultra-high strength

The overall design of the truck scale adopts the truck scale design software SCS-YB02, which is developed by the American universities for Youbao. It simulates the extreme operating conditions of the actual scale body and calculates the ultra-high strength and stable accuracy with the SCS-LZBC analysis method. Ensure the overall stiffness of the scale body > 1/1000, local strength BBB>0]. It fully conforms to the provisions of GB50017-2016 "Code for Design of Steel Structure".

The welding seam adopts HWM magnetic powder and ultrasonic flaw detection. The welding equipment adopts multi-head automatic welding machine for one-time precision welding. Each weld seam has a closed loop.

A variety of lap design for market differentiation choice.

Using the impulse hydraulic fatigue testing machine, the truck scale body through one million fatigue tests, simulate the truck scale in the actual use of the bad force into the situation

Perform fatigue test to verify the rationality of the design calculation and manufacturing process of the whole product.

SCS--YB02 calculates the pre-arch height for each truck scale, and combines the existing large hydraulic pre-arch machine to pre-arch the scale platform, effectively ensuring that the scale platform does not accumulate water and deform, and increasing the life of the scale body by 30% on average.

· Beautiful atmosphere

The use of special horizontal shot blasting machine on the scale blasting treatment, so that the surface roughness is less than 40-75μm, the surface meets the requirements of SA2.5 grade, in line with GB8923.1-2011 "steel surface corrosion grade and rust removal grade before coating". To ensure the adhesion of the paint.

Apply multilayer epoxy zinc-rich primer and Lanling brand two-in-one antirust topcoat with total film thickness ≥100μm. Thick oil film, wear resistance, pressure resistance, acid resistance, alkali resistance, corrosion resistance, suitable for all kinds of harsh weather and strong corrosive environment.
